Security Alarm Systems
HS2016 - PowerSeries Neo Security Control Panel
- 6 on-board zones
- Expandable to 16 wireless and hardwired zones
- 2 PGM outputs: expandable to 22 (HSM2204, HSM2208)
- Template programming
- Connect up to 8 supervised keypads with keypad zones
- 2 partitions
- 500-event buffer
- 48 user codes
- Interconnected smoke detector support with v1.2 allows for additional warning in potential life-threatening situations
HS2032 - PowerSeries Neo Security Control Panel
- 8 on-board zones
- Expandable to 32 wireless and hardwired zones
- 2 PGM outputs: expandable to 38 (HSM2204, HSM2208)
- Template programming
- Connect up to 8 supervised keypads with keypad zones
- 4 partitions
- 500-event buffer
- 72 user codes
- Interconnected smoke detector support with v1.2 allows for additional warning in potential life-threatening situations
HS2064 - PowerSeries Neo Security Control Panel
- 8 on-board zones
- Expandable to 64 wireless and hardwired zones
- 4 PGM outputs: expandable to 80 (HSM2204, HSM2208)
- Template programming
- Connect up to 8 supervised keypadswith keypad zones
- 8 partitions
- 500-event buffer
- 500 user codes (HS2064 E), 95 user codes (HS2064)
- Interconnected smoke detector support with v1.2 allows for additional warning in potential life-threatening situations
HS2128 - PowerSeries Neo Security Control Panel
- 8 on-board zones
- Expandable to 128 wireless and hardwired zones
- 4 PGM outputs: expandable to 148 (HSM2204, HSM2208)
- Template programming
- Connect up to 16 supervised keypads with keypad zones
- 8 partitions
- 1000-event buffer
- 1000 user codes (HS2128 E), 95 user codes (HS2128)
- Interconnected smoke detector support with v1.2 allows for additional warning in potential life-threatening situations
PC1616 - PowerSeries Control Panel
- 6 on-board zones
- Expandable to 16 hardwired zones
- Expandable to 32 wireless zones
- 2 PGM outputs: expandable to 14 (PC5204, PC5208)
- Connect up to 8 supervised keypads
- Supports wire free keypads with TR5164-433 transceiver
- Template programming
- 2 partitions
- 500-event buffer
- 48 user codes
- CP-01 compliant
- Compatible with leading edge interactive services supported by DSC
PC1832 - PowerSeries Control Panel
- 8 on-board zones
- Expandable to 32 hardwired zones
- Expandable to 32 wireless zones
- 2 PGM outputs: expandable to 14 (PC5204, PC5208)
- Connect up to 8 supervised keypads
- Template programming
- 4 partitions
- 500-event buffer
- 72 user codes
- CP-01 compliant
- Supports wire free keypads with TR5164-433 transceiver
- Compatible with leading edge interactive services supported by DSC
PC1864 - PowerSeries Control Panel
- 8 on-board zones
- Expandable to 64 hardwired zones
- Expandable to 64 wireless zones
- 4 PGM outputs: expandable to 14 (PC5204, PC5208)
- Template programming
- Connect up to 8 supervised keypads
- 8 partitions
- 500-event buffer
- 95 user codes
- CP-01 compliant
- Supports wire free keypads with TR5164-433 transceiver
- Compatible with leading edge interactive services supported by DSC
EnvisaLink EVL-4EZR For DSC & Honeywell Systems
- 100BaseT Ethernet Support
- Improved diagnostic LEDs to speed installation
- Remotely upgradable to allow for new features and services
- EnvisaLink TPI – programmer’s and integration interface
- EnvisaLink Expansion Header – add new hardware modules as they become available
- Simple to hook-up
- Built-in basic web server and html user-interface
- 128-bit encryption
- Real-time zone status with “time-since-tripped ” feature
- Local Arm/Disarm/Zone Bypass/PGM Control
- Multi-Partition Support
